Model | ETS-210-10S | ETS-310-10S | ETS-410-10S |
Overall dimensions/mm | W 500 H 1200 D 890 | W 600 H 1200 D 890 | W 600 H 1200 D 890 |
Tempeature range | -55℃～+180℃ | -65℃～+200℃ | -80℃～+220℃ |
Temperature change rate（no load） | -40℃～+85℃；+85℃～-40℃/10S |
Control Precision | ±1.0℃ |
Temperature setting and display precision | ≤0.1℃ |
Stability | ≤0.5℃ |
Temperature overshoot control | ≤1.0℃ |
Temperature control mode | Air temperature and DUT temperature can be controlled to switch |
Test operation mode | Program and fixed-value |
Comminication interface | LAN RS232/485 (GBIP port is also supported) |
Air input pressure | 90Psi～110Psi(20℃～28℃) |
Air input flow | 700L/min(25scfm) |
Dew point temperatrue | ≤10℃ |
Power | AC220V/380V ±10%,1PH /3PH,50/60HZ |
